HRT-P750D Differential Pressure Transmitter
Differential pressure transmitter for pressure-drop, flow and closed-vessel level measurement in industrial processes.
Specifications
- Measuring Range
- —-0.1 to 10 MPa family range
- Accuracy
- —By selected range
- Pressure Reference
- —Differential pressure
- Output
- —4-20 mA; other options by configuration
- Wetted Material
- —By pressure interface configuration
- Process Connection
- —Manifold / process connection options
- Electrical Connection
- —Field wiring connection
- Ingress Protection
- —IP65 baseline
Product Overview
HRT-P750D measures the pressure difference between two process points and converts it into a standard industrial signal. Differential pressure can be used directly for pressure-drop monitoring or as the measuring basis for flow and closed-vessel level applications.
Applications
Typical uses include filter differential-pressure monitoring, differential-pressure flow measurement with a primary element, and level measurement in pressurized vessels.
Selection & Application
Confirm the differential-pressure range, static pressure, medium, process connection and whether a manifold or local display is required.
Installation & Integration
Keep impulse lines as short as practical and arrange them so gas or liquid pockets do not create head errors. For liquid service, avoid trapped gas; for gas service, avoid trapped liquid. For steam or hot service, keep process temperature away from the transmitter through a suitable impulse-line arrangement.
Configuration Options
Range, output, manifold and local-indication options can be selected for the measuring task.
Next Step
For selection or quotation, please send the medium, differential-pressure range, static pressure, process connection and required output.
