HRT-L180R Compact 80GHz FMCW Radar Level Transmitter
Compact 80 GHz FMCW radar level-transmitter family for non-contact measurement. Vessel geometry, medium, nozzle, obstructions, range and antenna/process connection require application review.
Specifications
- Technology
- 80GHz Frequency Modulated Continuous Wave (FMCW)
- Measuring Range
- 8 Meters / 15 Meters
- Housing/Antenna Material
- PP / PVDF / PTFE / PFA (Integrated design)
- Signal Output
- 4-20mA (2-wire) / RS485 (4-wire)
- Process Connection
- G1", G1½", G2" Threaded
- Process Pressure
- -1 to +3 bar
- Operating Temp
- -20°C to +70°C
- Commissioning
- Bluetooth App Control
- Media Type
- Liquids, Slurries, and Granular Solids
- Customization
- Bespoke engineering for specific tank and process conditions
What this product is
Compact 80 GHz FMCW radar level-transmitter family for non-contact measurement. Vessel geometry, medium, nozzle, obstructions, range and antenna/process connection require application review.
Application fit
This level product can be reviewed only after the measurement principle is matched to the medium, vessel or site geometry, range, mounting arrangement and required interface.
Selection information required
- Medium properties, density or dielectric behavior where relevant.
- Range or depth, vessel/site geometry, nozzle, obstacles and mounting position.
- Process temperature, pressure, vapor, foam, condensation and environmental exposure.
- Output or communication, power, cable routing, venting and maintenance access.
Installation and integration
For radar, review nozzle, obstructions and target conditions. For hydrostatic measurement, review density, venting, cable routing and mounting depth. For capacitance measurement, review probe arrangement and dielectric behavior.
Verified specifications
Use only specifications confirmed for the exact model and ordered configuration. Unverified numerical ranges, accuracy, materials, protection ratings, certifications, protocols and performance claims are intentionally not stated here.
Limitations and review conditions
Product names or family labels do not by themselves prove hazardous-area approval, waterproofing, corrosion resistance, hygienic suitability, wireless capability or compatibility with a particular medium or control system. Check the exact documentation and configuration before selection.
Next step
Contact our technical team with the medium, range, process conditions, connection, output and installation details to request a configuration review.
